1/2.5''CMOS High-Resolution TI Da Vinci DSP IP dome camera -...

Model

MIP-813T2-POE

Hardware

Sensor

1/2.5''CMOS High-Resolution TI Da Vinci DSP

Resolution

1920×1080

Frames

5MP: 2592x1920@10FPS

3MP: 2048x1536@15fps,

2MP: 1920x1080@30fps

Day/Night

Auto,dual IR-Cut filter

IR LED

42pcs Ø5 IR Leds  IR Range 40 m (98.43feet)

Max S/N Ratio

39dB

Electronic Shutter

Rolling Shutter

POE Funtion

 YES

Interfaces

Optical lens

Interface

CS mount (Interchangeable Lens)

Lens

Fixed Iris, Manual Focus

Focal Length

Varifocal Lens 2.8-12mm - 2 Megapixels Lens

Network Interface

Lan

10/100M BASE-TX,RJ-45 Safe-adaption

Video Compression

H.264 Main Profile; MJPEG/JPEG Baseline

Audio Interface

1×Line In,1×Line Out (optional)

Video Bitrate

32Kbps～4Mbps,Supports CBR/VBR

Control Interface

1×RS485 (optional)

Alarm Interface

1×input，1×output (optional)

Image Orientation

image flip and mirror

Auto Image Control Functions

Auto  Exposure Control (AEC);

Auto White Balance (AWB); (AGC)

Auto Black Level Calibration (ABLC)

Image Controls

Color saturation, hue, gamma, sharpness (edge enhancement),

 lens correction,

defective pixel canceling, and noise canceling

Network protocol

TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、

DDNS、DHCP、NTP、SMTP、UPNP

ONVIF protocols

Support

Remote View

PC

IE 6.0 or later, max 5 users

General Parameters

Environmental Casing

Waterproof (IP66  Rated), Outdoor Use

Installation

Brackets Included, Wall Mount

Operating Temperature

 -20 °C ~ 60 °C

Operating Humidity

0% -90% RH

Power

DC12V 2.0A

Power Consumption

≤6W

Dimension

290mm(L) x 93mm(W) x 79mm(H)

Weight

1.5 KG

Approvals

CE FCC RoHS
