Housing for IP cameras for installation in aggressive...

Housing for IP cameras for installation

in aggressive environments

NXM36 Hi-PoE

DESCRIPTION

The NXM36 Hi-PoE housing has been developed for installations in highly corrosive

areas such as industrial chemical, petrochemical, marine, naval and offshore platforms.

Entirely made from electropolished and passivated AISI 316L stainless steel for maximum

protection against deterioration.Weatherproof IP66/IP69/IP68, it provides a complete

protection against dust and it’s submersible down to 40m (130ft).

KEY FEATURES

Made of AISI 316L electropolished stainless steel

PoE/Hi-PoE to power heater & network camera

Category 5e shielded power cable

Compatible with IEEE 802.3af, IEEE 802.3at/PoE Plus

IP66/IP69/IP68, submersible down to -40m (-130ft), equal to 5bar max pressure

Cylindrical body enclosed by two 6mm(0.24in)-thick circular flanges

2 PG13.5 cable glands in nickel-plated brass for external connections
