Display
|
960*320 high-definition 2.4-inch LCD screen
|
|
Video input
|
CVBS
|
|
Video recording
|
AVI
|
|
Video Resolution
|
PAL 720*480 at 30 FPS,NTSC 720*576 at 25 FPS
|
|
Memory type
|
SD card(over 32GB)
|
|
Recording time
|
20-60 minutes/1GB SD card
(high resolution-20min,middle resolution-40min,lowresolution-60min) |
|
Audio alone recording
|
Yes
|
|
Take Photo
|
Yes,
|
|
Audio/video out cable
|
CRA cable
|
|
PC interface
|
USB 2.0
|
|
Operation current
|
DC5V 180mA
|
|
Removable Bettery type
|
3.7V/1Amp lithium-iron battery
|
|
Battery lifetime
|
2-3hours (including external HD camera)
|
|
Vibration alert
|
without video signal or without SD card or starting recording or stopping recording
|
|
Recording max bps
|
10M
|
|
Date&Time stamp
|
Real-time recordings are marked in File
|
|
Digital Zoom
|
null
|
|
Output power for external camera
|
5V,500MA
|
|
Can make ID for every unit
|
Yes
|
|
Wireless control
|
IR remote control
|
|
Wired control cable
|
Yes,Power on record
|
|
imensions
|
78mm*51mm*22mm
|
|
Net Weight
|
70g without the battery respectively
|
Engelsk manual
