IP66 Waterproof Night Vision IR-Cut 940nm Minitype Small Mini...

8MP 4K

18 andre varer i samme kategori:

 IP66 Waterproof Night Vision IR-Cut

940nm Minitype Small Mini POE IP


8MP 4K Feature

Supporting Face detection, Humanoid detectionn, and supports customization of

other smart functions;

8.0MP HD Black light illumination resolution, clear and fine images;

Support 2D/3D noise reduction, digital wide dynamic;

Advanced H.265(Compatible with H.264) video compression, Super low rate, high definition

quality of image;

Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5;

Support ONVIF, access third party;

Support various mobile monitoring(iPhone, Android);

OS

Parameters

4K 8MP

kernel

System

Linux

Processor

Mstar

Video

Image sensor

8MP Super Low illuminance COMS image sensor

Video Codec

H.265 main profile and baseline

LEN

3.6mm

IR LED

10pcs 940nm LED

IR distance

1-10M

Support mobile phone

All phone

P2P

PHONE,IE,P2P Client global Internet

Video Resolution

First stream:4K 8MP(3840*2160)@15fps/5MP(2880*1624)@25fps/4MP(2560*1440)@25fps/

3MP(2304*1296)@25fps/2MP(1920*1080)@25fps can be set

4K 8MP(3840*2160)

Second stream:1280*720,800*448,704*576,640*360

Three stream:640*360/352*288

frame rate

8MP:15fps,5MP:25fps,4MP:25fps,3MP:25fps,2MP:25fps

Video compression

32Kbits/S~12280Mbits/S

Min.Lux

Color>0.01 LUX B&W<0 LUX

Store

SD card

NA

Client/Browser

Support

Record

Client

support

Browser

Support

SD CARD

not Support

Playback

Client

support

Browser

Support

SD CARD

not support

SD Card



not support SD card



Audio

Audio input

Mic is builded in camera

Audio output

SNA

Audio Codec

G.726/G.711

Internet

Internet face

10Base-T/100Base-TX, POE

Network Protocol

TCP/IP,https,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP

Access Protocol

ONVIF

Alarm

Motion detection

At most 4 respective regions

Alarm linkage

Alarm picture send E-mail, alarm images upload FTP server

Snap

Time snap

Regular support capturing images to the FTP server

safe

User management

Provide three levels of rights management (admin, user, guest), support to modify login user name and password

Other

Inter Power,consumption

DC12V 2A/POE (The package does not provide a power adapter)

Working temperature

-40℃ ~ +55℃

Working Humidity

10-95%

Note: If you need POE power supply, select the ADD POE option. If you do not select POE power supply, it is normal cable
