20M Sewer Waterproof Camera Pipe Pipeline Drain Inspection...

 20M Sewer Waterproof Camera

Pipe Pipeline Drain Inspection System

7"LCD DVR

Attentions

1.Read the instructions seriously prior to utilization.

2.No throwing or pressure with strength.

3.No guarantee repair for users’ voluntary unpacking or spoilage.

4.Copy your materials prior to connection of SD card, for any results caused by material loss, the factory bears no responsibility. (for recording type)

5.No sudden outage in video and play, this may destroy products and video files. (for recording type)

Range of Application

1.Use it with mini-video camera with the tube diameter as 23-120MM

2.Water-supply pipe

3.Air-conditioner pipe

4.Cable pipe

5.Pipeline vacuum system

6.PLUNBIN pipe

7.Buildings

8.Sunken pipe

Product Specification

Item: parameter

1.Charger: AC100-240V   DC12.6V  1000MA

2.Battery: Luminal-cell arrester4AH

3.continuous use time for battery: approximate 8h

4.investigation depth: 20M( selectable line length)

5.material: fiber tube with /high intensity

6.camera light source: 12 LED with high while light(adjustable)

7.camera viewing angle: 110°

8.camera size/material: 120MM* 23MM /stainless steel

9.camera protective cover parts size/material:40MM* 30MM /plastic-steel

10.camera depth: 400MM (approximate)

11.camera picture: color

12.SD card: max. support 32G, factory configuration 2G (for recording type)

13.Operating temperature: -20-60°

14.Storage temperature: -50-60°

15.Aluminum box size: 375*265*135mm

16.Package size: 400*165*345mm
