Ubiquiti TOUGHSwitch PoE 8-port Gigabit

Ubiquiti TOUGHSwitch PoE 8-port Gigabit

Data Ports (8) 10/100/1000 Ethernet Ports

Features

Ubiquiti ToughSwitch PoE PRO, 8 Gigabit PoE Ports, 24V or 48V Configurable Passive PoE, Configuration Interface

Gigabit Ethernet performance combined with Industrial strength construction and a 150Watt power supply. The TOUGHSwitch PRO version is capable of powering up to eight 24V or 48V devices with software selectable output voltage control. It is the ideal PoE solution for use with Ubiquiti airMAX base station deployments.

Specifications

Dimensions 210 x 185 x 41 mm
Weight 1.24 kg
Power Input 110-120VAC / 210-230VAC
Max. Power Consumption 150 W
PoE Out Voltage Range 45-48VDC / 22-24VDC
Max. PoE Wattage Per Data Port 18W
ESD Rating 24 kV Air / 24 kV Contact
PoE Method Passive
Button Reset
USB Port 2.0 Type A (Reserved for Future Use)
Processor MIPS24K 400 MHz
System Memory 64 MB
Code Storage 8 MB
Certifications CE, FCC, IC
Operating Temperature -25 to 55°C (-13 to 131° F)
Operating Humidity 90% Non-Condensing
PoE Configurable Per Port
Management Port N/A
Data Ports Off/24V/48V
LEDs Per Port
Management Port Power/Link/Activity
Data Ports PoE, Speed/Link/Activity
Networking Interfaces
Management Port (1) 10/100 Ethernet Port
